JT01010EPS-2
MX23A Series,Wire to Borad,Pitch 2.5, Terminal, Phosphor Bronze,Tin Plating,0.3,Reel
Product Introduction
MX23A connector is a compact, low-profile, waterproof connector that can be used in a wide range of waterproof equipment including automobiles, motorcycles and other outdoor equipment.
This connector has high environmental capability with a waterproof structure consisting of a seal ring in its mating area and a grommet in its wire insertion area for full protection against water.
Parameter
| Product type Features | Series | MX23A(040) | Products Category | Wire to Board |
| Male/Female | - | Pitch(mm) | 2.5 | |
| Configuration Features | Row | - | Number of Positions | - |
| Applicablewire range | AVSS 0.3 | Applicable Contacts | - | |
| Receptacle Style | - | Mating Connector | JH00010**FBA-A | |
| Specifications and Features | Material-Plastic | - | Flame retardancy | - |
| Material-Metal | Phosphor Bronze | Plating | Tin plating | |
| Color | - | |||
| Packaging Features | Packling | Reel | SPQ | 7000 |
| Other Features | Waterproof | - | Original Factory Model | M23S05K4F1 |
| Electrical Features | Rated current | 3A | Rated voltage | - |
| Operating Temperature | -40-120°C | Withstand Voltage | 1000V/AC 1Mintue | |
| Contact resistance | 10mΩ Max | Insulation resistance | 100MΩ Min |
